Industrial Piping Project Experience & Representative Capabilities
Demonstrated execution capabilities across Qatar’s most demanding industrial sectors. In strict accordance with our truth-in-marketing policy, representative capabilities are categorized by sector, metallurgy, and code standards.
Oil & Gas Upstream & Gathering
Execution Scope: High-pressure wellhead flowline fabrication, manifold tie-ins, and cross-country gathering spools.
- Materials: API 5L Gr. B / X52 / X60 PSL2 (NACE MR0175 sour service compliant)
- Pipe Sizes: NPS 4" to NPS 24" (Sch 40, Sch 80, Sch 120)
- Governing Codes: API 1104, ASME B31.4, NACE MR0175 / ISO 15156
- Fabrication: Shop prefabrication of wellhead headers; field golden weld tie-ins under live plant permits.
- Testing & QA: 100% PAUT / Radiography, Magnetic Particle testing on weldolets, hydrostatic test up to 210 bar.
Liquefied Natural Gas (LNG) & Gas Processing
Execution Scope: Cryogenic process spool prefabrication, boil-off gas piping, and plant shutdown tie-in spools.
- Materials: ASTM A333 Gr. 6 (LTCS), ASTM A312 TP304L/316L, Super Duplex UNS S32750
- Pipe Sizes: NPS 1/2" to NPS 48" (Sch 10S to Sch 160)
- Governing Codes: ASME B31.3 Chapter IX, ASME Section IX, Shell DEP / QatarEnergy specs
- Fabrication: Dedicated clean-bay fabrication with argon backing purge (< 20 ppm O2) and orbital TIG welding.
- Testing & QA: 100% Volumetric NDT (RT/PAUT), Charpy impact testing at -196°C, helium leak testing.
Petrochemical Refining & Fertilizers
Execution Scope: High-temperature cracking furnace coils, sulfuric acid lines, and ammonia synthesis spools.
- Materials: ASTM A335 P11 / P22 Chrome-Moly, SS 904L, PTFE-Lined Carbon Steel
- Pipe Sizes: NPS 2" to NPS 36" (Heavy wall up to 35mm)
- Governing Codes: ASME B31.3 Category M, ASTM F1545
- Fabrication: Controlled multi-pass GTAW/SMAW welding with automated multi-zone PWHT chart recording.
- Testing & QA: 10kV spark testing on PTFE liners, Phased Array UT, hydrostatic testing at 1.5x design pressure.
Seawater Desalination (SWRO)
Execution Scope: High-pressure reverse osmosis membrane feed headers, energy recovery loops, and brine outfall headers.
- Materials: Duplex 2205 (UNS S31803) & Super Duplex 2507 (UNS S32750) with PREN >= 42
- Pipe Sizes: NPS 1" to NPS 32" (Sch 40S, Sch 80S)
- Governing Codes: ASTM A790, ASME B31.3, NORSOK M-601
- Fabrication: Precision heat input control (0.5–1.2 kJ/mm) using ER2594 wire with argon-nitrogen backing purge.
- Testing & QA: Ferrite scope checks (35–65% ferrite), ASTM A923 Method C ferric chloride pitting test, hydrotest.
District Cooling Central Plants
Execution Scope: Primary chilled water evaporator headers, condenser water loops, and underground pre-insulated transmission mains.
- Materials: ASTM A53 Gr. B / API 5L Gr. B Carbon Steel with PUR foam insulation and HDPE outer casing
- Pipe Sizes: NPS 8" to NPS 56" (DN200 to DN1400)
- Governing Codes: QCS 2014 Section 21, EN 253, ASME B31.1
- Fabrication: Heavy header prefabrication with mechanized SAW welding; field casing shrink sleeve jointing.
- Testing & QA: 100% ultrasonic weld testing on underground joints, electronic leak detection wire continuity, hydrotest up to 25 bar.
Hygienic Dairy & Food Processing
Execution Scope: Sanitary milk reception manifolds, HTST pasteurizer interconnecting lines, and automated CIP loops.
- Materials: ASTM A270 TP316L Sanitary Stainless Steel (Internal polish Ra < 0.5µm)
- Pipe Sizes: NPS 1" to NPS 4" sanitary tube with tri-clamp connections
- Governing Codes: ASME BPE, 3-A Sanitary Standards, EHEDG
- Fabrication: Closed-chamber automated orbital TIG welding with 99.999% argon purge and zero dead legs.
- Testing & QA: 100% video borescope inspection of internal root beads, profilometer roughness profiling, passivation.
Qatar Piping refrains from inventing client names, exaggerated completion values, or artificial project photos. Actual completed case studies and reference contacts are provided directly to qualified clients under mutual non-disclosure agreements during formal tender pre-qualification.
Request an Industrial Piping Quotation or BOQ Review
Submit your piping schedule, isometric drawings, or material take-offs. Our technical engineering team evaluates specifications to deliver accurate pricing and execution schedules.
